Photoelectric Sensor

Product Details:

Carlo Gavazzi PA18CSD04PASA-5M. Its a through beam sensor set specially designed for Elevators, Escalators, Entrance control to meet the requirements in the door market. The housing is very robust and is known for its high long-term reliability mute. The emitter has a mute input to turn it off for evaluation of the sensor function.

Additional Information:

• Delivery Time: immediate

Product Details:

The LD30CPBR60BPxxIO are a part of the latest generation of high performance Photoelectric Laser sensors designed to solve challenging detection tasks due to Laser, Background Suppression, Foreground Suppression and Dual Detection features. The small light spot makes detection very precise. The sensors are implemented in the compact 10 x 20 x 30 mm ABS housing that are acknoledged world wide. New implemented functions with weight on functionality, reliability, Predictive maintenance make these sensors ideal for Industry 4.0.

The detection distance is almost independent of the colour of the object to detect.
• The sensor can be operated in IO-Link mode once connected to an IO-Link master or in standard I/O mode.
• Measured sensing distance as process data.
• Neighbour interference protection.
• Sensing distance by teach-button, teach by wire or by IO-link parameter.
• Quality of Run and Quality of Teach result.
• Temperature data for preventive maintenance.
• Front-end check for preventive maintenance.
• Dual Detection

Product Details:

The LD30CNBI10BPxxIO sensor family comes in a compact 10 x 30 x 20 mm ABS housing. They are designed for use in applications where high-accuracy detection as well as small size is required. Compact housing and high power LED for excellent performance-size ratio. The compact sensor design is ideally suited to confined spaces.

• The sensor has multiple detects functions e.g. in single point mode the presence or absence of objects are detected while cutting off the background information.
• The detection distance is very independent of the colour of the objects to be detected.
• The “analogue” distance from the sensor to the object is available via the IO-Link communication.
  The sensor can be operated in IO-Link mode once connected to an IO-Link master or in standard I/O mode. Adjustable parameters via IO-Link interface:
• Sensing distance and hysteresis
. • Sensing modes: single point or two point or window mode
. • Timer functions, e.g.: On-delay, Off delay, One shot leading edge or trailing edge.
• Logic functions such as: AND, OR, X-OR and SR-FF.
• External input.
• Logging functions: Maximum temperatures, minimum temperatures, operating hours, operating cycles, power cycles, minutes above maximum temperature, minutes below minimum temperature, etc.
• Auto hysteresis

Product Details:

The PA18CSD.. is a family of inexpensive general purpose Diffuse-reflective sensors in industrial standard 18 mm cylindrical PBTP housing. They are useful for simple applications where a basic sensor provides adequate sensing performance. The sensors are simple to use and no adjustment are necessary (except 400 mm diffuse adjustable type). The output is a 4-wire complementary (NO and NC) output in NPN (current sinking) or PNP (current souring).

Range: 400 mm adjustable 100, 200 or 400 mm fixed
• Modulated, infrared light
• Supply voltage: 10 to 40 VDC
• Output: 200 mA NPN or PNP
•Make and break switching function, LED indication
• Protection: Reverse polarity, short-circuit, transients
• High immunity to ambient light
• Cable and plug versions

Product Details:

Carloagavazzi VP03EP Optical level sensor with un modulated,  infrared light for the detection of liquids. Fitted with built-in amplifier. Trans mitter and receiver are completely self-contained in solid plastic housing designed for mounting intocontainer wall. VP01/02 are available in a Polysulphone housing resistant to most acids and bases.  VP03/04 are available in a Polyamide 12 housing resistant to various solvents.
