Safety light Curtain


We are a leading Importer of safety light curtains, safety light curtain and light curtain from Chennai, India.

REQUEST CALLBACK
  • +3
Get Best Quote

Approx. 15,000 / Piece Get Latest Price

Product Brochure
Product Details:
Operating Temperature-10+ 55 degC
Storage Temperature-25+ 70 deg C
Cables Length50 m
Emitting LightInfrared, LED (950 nm)
BrandCarlo Gavazzi
Operating Distance0.2-19 m
Ambient Light RejectionIEC-61496-2
Humidity15-95% (no condensation)
Power Supply24 Vdc +/- 20%
Unit Current Draw2 W
Protected Height150-1500 mm

The safety light curtains of the SC2 senes are optoelectronc mudibeam devices that are used to protect working areas that. in presence of machines, robots. and automatic systems in general, can become dangerous for operators that can get in touch, even accidentally, with moving parts. The light curtains of the SC2 senes are Type 2 intnnsic safety systems used as accident-prevention protection devices and are manufactured in accordance with the international Standards in force for safety, in particular:
  • CEI IEC 61496-1: 2004 Safety of machinery: electro-sensitive protective equipment. Part 1: General prescriptions and tests.
  • CEI IEC 61496.2: 2006 Safety of machinery: Sectro-sensitNe protective equipment. Particular requirements for equipment using active optoelectronic protective devices.
The device. consisting of one emitter and one recervet housed inside strong aluminium prof Iles. generates infrared beams that detect any opaque object positioned within the light curtain detection field. The emitter and the receiver are equipped with the command and control functions. The connections are made through a M12 connector located in the lower side of the profile. The synchronisation between the ender and the receiver takes place optically, i.e. no electrical connection between the two units is required. The microprocessor guarantees the check and the management of the beams that are sent and received through the units. The microprocessor - through some LEDs - informs the operator about the general conditions of the safety light curtain (see section 7 'Diagnostic functions"). The device consists in 2 units that, according to the model, are composed by one or several emitting and receiving modules. The receiver checks the control operations and safety actions.

Yes! I am interested


REQUEST CALLBACK
  • +1
Get Best Quote

Approx. 10,500 / Piece Get Latest Price

Product Details:
Power SourceElectric
Output MethodNPN NO & NPN NC two way output
Protection ClassIP-65
Output current100 mA
ApplicationSafety and Restricted Area
ModelNA-04
Sensing Height120 - 760 mm
Sensible ObjectOpaque Object 45
Operating Voltage24+-20% VDC, +-20% P-P Max
BrandCarlo Gavazzi
Beam Pitch40 mm
Setting Distance0.5 m~5.0 m
Protection CircuitShort Circuit & Polarity Reversed Protection

Safety Light Curtain that is mainly used in operator safety and restricted area. The offered light curtain or safety guard is meticulously tested on various quality parameters. Provided curtain is manufactured by utilizing optimum quality raw material and latest technology by our vendor’s. In line with industry standard, we provide the entire range in various customized options and at affordable price.

Features:

  • Rugged design
  • Reliable operation
  • Unmatched performance
  • Made in taiwan
  • ultra slim size

Yes! I am interested


REQUEST CALLBACK
  • +1
Get Best Quote

Approx. 24,587 / Piece Get Latest Price

Product Details:
Voltage24VDC
Automation GradeAutomatic
Beam Pitch40mm
Suitable Forhand safety or operator safety
Output Typepnp or npn
Operating Voltage230vac
BrandFotek
MaterialAluminum
Alarm Current100mA
CertificationCE Certified
ColorYellow & Silver
DesignLight Curtain
Is It Water ProofYes

Safety Light Curtain that is mainly used in operator safety and restricted areaThe offered light curtain or safety guard is meticulously tested on various quality parameters. Provided curtain is manufactured by utilizing optimum quality raw material and latest technology by our vendor’s. In line with industry standard, we provide the entire range in various customized options and at affordable price.

Features:

  • Rugged design
  • Reliable operation
  • Unmatched performance
  • Made in taiwan
  • ultra slim size
Appending EMC enhanced circuit.
  • Sensing Distance: 0.5m~6m
  • NA Series Beam Pitch :40mm
  • LC Series Beam Pitch :25mm
  • Two way output : NPN/NO & NPN/NC
  • Output Protection: Short circuit protection.

Yes! I am interested


REQUEST CALLBACK
  • +1
Get Best Quote

Approx. 10,000 / Piece Get Latest Price

Product Details:
Protection CircuitShort circuit & polarity reversed protection
Make Step20 mm
BrandFotek
Setting Distance0.5m~5.0m
Working Environment Temperature-10 deg C to 55 deg C
Supply voltage24V
Number of Light Beam4-32 beam
Prower consumption15 W
IP RatingIP-65

Our firm specializes in offering an excellent range of Light Curtain that has strong body to withstand the vibrations. To maintain industry defined quality standards, this curtain is manufactured using quality proven raw-material and cutting-edge technology. Also, the entire range is examined properly by our quality experts upon distinct parameters of quality. In line with industry set standard, we provide this curtain in various sizes and shapes as per the ever-evolving needs of our clients.

Features:

  • Strongly built
  • Rust resistance
  • Long operational life
